New 140t solid fuel rocket engine.

If the configuration of the building is still 4m high, the cylinder diameter of the engine is about 1.5 to 1.6m.

At the same time, however, it was pointed out that the diameter of the engine should be 2.1 meters if the height of a person is 1.75 meters.





View attachment 1671203485221.png

A New-type of missile which maybe based on Hwasong-12.
There is only one main engine and different shape designs.
But at the same time, there are many characteristics that show that it is mainly designed based on hwasong-12.
And its range is longer than hwasong-12(~3700).






View attachment 1671203602383.png

View attachment 1671203613764.png




















According to his height, it is speculated that the height of the building may reach 6 meters, so it can be inferred that the diameter of the rocket engine may reach 2.3-2.4 meters (as you speculate).



In the DPRK, the military received 30 sets of giant MLRS with a caliber of 600mm, which can also be used to launch tactical nuclear missiles. There are no technical details of the settings. It is known that MLRS data missiles have a high ability to bend around the terrain, as well as maneuverability and high speed. On January 1, 2023, the North Korean military performed a training launch from a single installation. The projectile covered 350 kilometers with a maximum flight altitude of 100 kilometers and hit a given area of the Sea of Japan east of the Korean Peninsula. In the DPRK, there are two more variants of the 600mm MLRS on an 8 = 8 wheeled chassis.


  • Informative
Reactions: jetray
In the capital of the DPRK, Pyongyang, on February 8, a night military parade was held in honor of the 75th anniversary of the founding of the Korean People's Army. The parade, along with his wife and daughter, was hosted by North Korean leader Kim Jong-un. The parade is not particularly different from all past parades, except that a record number of military personnel took part in it and an unknown new DPRK tank was again shown. This tank has been noticed at parades for more than a year, but so far nothing is known about it. The tank does not even have a name, it is called differently, the M-2020 tank, the Storm tank. Visually, the M2020 tank is similar to the American M1 Abrams tank and the Russian T-14 Armata. The tank has enhanced armor in the lateral projection and on the sides. The gun of the tank is a 125-mm Russian 2A46 cannon, the tank has a machine gun coaxial with the gun and an AGS-30 grenade launcher. The tank has two Bulsae-3 ATGMs, it is believed that it was developed on the basis of the Russian Fagot and Kornet ATGMs. For the first time on the tanks of the DPRK, an active protection system for tanks was installed, it can be seen at the base of the tank turret, visually the complex resembles the Russian Afghanit system installed on the T-14 Armata tank, sensors of possible active protection systems are located in the front corners of the tower. Panoramic sights are located on the roof of the turret, it is possible that the tank has a thermal imager. It is not excluded that many systems are still props. It is assumed that the M2020 tank is equipped with an engine with a capacity of 1200 horsepower, the estimated mass of the tank is about 55 tons. There are suggestions that the tank was created using the technology of Russia and China.


The North Korean army for the first time showed footage of launches of strategic cruise missiles of the Hwasal-1 and Hwasal-2 types. The cruise missiles were equipped with a "test warhead simulating a nuclear warhead" and flew between 1,500 and 1,800 km. The launch of cruise missiles was a response to the US and South Korean military exercises Freedom Shield 23, which we talked about earlier. The North Korean exercise tested the reliability of control devices and detonators in a mid-air explosion and demonstrated yet another military strike capability. Two Hwasal-1 and Hwasal-2 strategic cruise missiles launched in South Hamgyong Province accurately hit a target in the Sea of Japan.
